1mm diameter pt100 stainless steel temperature sensor

Brand Name : GME

Model Number : GME-1mm pt-100

Certification : ISO9001

Place of Origin : China

MOQ : 10pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 7-15days

Packaging Details : Standard Export Packing

Diameter of probe : 1mm

Material : stainless steel 304

Accuracy : Class1

Usage : Industrial

Type : PT-100

TYPEWire material : fiberglass shielding wire

Probe length : 100mm

Contact Now

1mm diameter pt100 stainless steel temperature sensor

Features:

Minimum diameter: 1mm

Accuracy: class1

Material:stainless steel 304

Specification:

type	pt100
temperature range	0-400℃
probe diameter	1mm
probe length	100mm
probe material	SS304
wire length	1000mm
wire material	fiberglass shielding wire

Pictures

1mm diameter pt100 stainless steel temperature sensor

temperature sensor PT100

Code

Mark

Use temperature

Protection tube

materials

Class of accuracy and allowable error

GME

PT100

-200~500°C

304

321

316L

Grade A:

+/- (0.15+0.002%|t|)

Grade B:

+/- (0.3+0.005%|t|)

Pt thermal		Graduation mark	±(°C)Et value on various temperature spots										R100/R0
			-200	-100	0	100	200	300	400	500	600	650
Pt RTD	Grada	Pt10 0	0.55	0.35	0.15	0.35	0.55	0.75	0.95	1.15	1.35	1.45	1.3850±0.0005
	A	Pt10
	Grada	Pt100	1.3	0.8	0.3	0.8	1.3	1.8	2.3	2.8	3.3	3.6	1.3850±0.0012
	B	Pt10
Cu RTD		Cu50	1.5	0.9	0.3	0.9	1.5	2.1	————	————	——	————	1.428±0.002
		Cu100

Sensor Type	RTD Pt100 element
Sensor Type	PPCK: RTD Pt1000 element
Probe Diameter	1mm-6mm
Detector Elements	Simplex (1 channel)
Detector Elements	Duplex (2 channels)
Probe Length (mm)	As required to suit your application
Wiring Configuration	2-wire
	3-wire
	4-wire (Simplex only)
Grade of Element	B (Accuracy: ±0.30°C at 0°C, ±0.80°C at 100°C)
Grade of Element	A (Accuracy: ±0.15°C at 0°C, ±0.35°C at 100°C)
Cable Length (mm)	As required to suit your application
Extension Cable	PVC Insulated (+105°C), 2, 3, 4-wire
	PFA Insulated (+250°C), 2, 3, 4, 6-wire
	Fibreglass/SSB (+400°C), 2, 3, 4-wire
Optional RTD Connector	Miniature RTD Plug
	Miniature 3-Pin RTD Plug
	Standard RTD Plug
	Standard 3-Pin RTD Plug
Optional 316 Stainless Steel Compression Fittings	To suit probe Ø: 1mm, 1.5mm, 2mm, 3.0mm, 4.0mm, 4.5mm, 6.0mm

Application:

For food temperature measurement;

Also for liquid and gel temperature measurement;

Entire probe covered with metal coating protection;
